Lindy SPLITTER DISPLAY PORT TO 2xDISPLAY PORT (MST-Expands or duplicates)

Κωδικός plus26: 173-436484

Κωδικός Εργοστασίου (MPN): 38430

Εγγραφείτε για τιμή

Connect 2 DisplayPort displays to a DisplayPort computer or laptop

Expand, duplicate or display independent DP signals over dual DP monitors

Supports resolutions up to 2 x 4K 30Hz, and audio up to 7.1CH

Compatible with various graphics cards including AMD Eyefinity, NVIDIA Surround and Intel Collage

2 Year Warranty

The Lindy 2 Port DP MST Hub is an ideal solution for expanding or duplicating DisplayPort signals across 2 DisplayPort monitors. MST hubs allow for the connection of a single DP source device including computers, laptops or notebooks to 2 separate DP displays, while also providing the ability to visualise content in multiple ways. Signals can be expanded across both displays to show large scale spreadsheets, create immersive panoramic gaming experiences or eye-catching digital signage in retail. Content can also be, independently shown on either display, great for developing a productive, multi-tasking working environment, or duplicated on both displays for use in hospitality, retail or educational scenarios.
With support up to 3840x2160@30Hz 4:4:4 8bit, content can be viewed in ultra-realistic quality, ideal for applications that require a high resolution output such as graphic design, while compatibility with a variety of graphics cards including AMD Eyefinity, ensures issue free multi-screen playback.

Please note: This hub is not compatible with Apple products

Specifications

AV Interface: DisplayPort
Interface Standard: DP 1.2
Supports Bandwidth: 21.6 Gbit/s
Maximum Resolution: 2 x 3840x2160@30Hz 4:4:4 8 bit
HDCP Support: HDCP 1.4
Supported Audio: Up to 7.1CH
Separate Audio Ports: -
CEC Support: -
Serial Interface: -
Special Features: -

Connectors

Input: DisplayPort (Male)
Output: 2 x DisplayPort (Female)
Control: -
Power : Micro-USB (Female)

Physical Properties

Dimensions (approx.) WxDxH: 254x49x10mm (10x1.93x0.39in)
Housing Material: ABS
Net Weight: 0.055kg (0.12lb)
Operating Temperature: -20°C - 40°C (-4°F - 104°F)
Storage Temperature: -40°C - 80°C (-40°F - 176°F)
Humidity: 5-90% RH (Non condensing)
Power Requirements: 5VDC 0.5A
Colour: Black

Miscellaneous

Packaging Type: Polybag
Packaging Dimensions: 174x194x10mm (6.85x7.64x0.39in)
Gross Weight: 0.062kg (0.14lb)
Warranty (Years): 2
Product Compliance: CE, UKCA, FCC, RoHS & REACH

Package Content

DisplayPort MST Hub
USB Micro-B to USB Type A Cable

Purchasing Information

No.: 38430
EAN: 4002888384308
