Category
6A (TIA)

Type of connector connection 1
RJ45 8(8)

Type of connector connection 2
RJ45 8(8)

Connector type
RJ45 Standard yellow

Contacts
Gold plated

Pin assignment
1:1

Allocation
acc. TIA/EIA 568B

Type
Shielded

Length imprint
yes

Anti-kink sleeve
moulded

Colour anti-kink sleeve
green

Locking lever
yes

Mating cycles
≥750

Bending radius
>32,5 mm

Conductive shield
Selected shield contact

Raw cable
Cat.7

Cable type
S/FTP

Cable construction
4x2

AWG-size
26/7

Conductor Material
Copper

Silicone-free
yes

Jacket material
LSZH

Colour outer sheath
green

Printing
Cat.7 raw cable S/FTP 4x2xAWG26/7 PIMF 600MHz ISO/IEC 11801 & EN50173-1 TIA/EIA 568B-2.1 Halogen Free ***10GIGABIT***

Outer diameter of the cable
6.5 mm

Flame-retardant
acc. IEC60332-1

Halogen-free
acc. IEC60754-2

Low smoke
acc. IEC61034

Temperature range
-20 – 60 °C

Impedance
100 ±5 Ω

Conductor resistance DC
146 Ω/km

Loop resistance
292 Ω/km

Resistance unbalance
5 %

Insulation resistance
10 MΩ

Contact resistance
30 mΩ

Test voltage
1000 (V DC, 1min) core/core und core/screen

POE class
PoE acc. to IEEE802.3af;PoE+ acc. to IEEE802.3at;4PPoE acc. to IEEE802.3bt

Bandwidth
500MHz

Transmission
10Gbit

Connector
IEC 60603-7-51
