Gigabit Ethernet Media Converter, Multimode SC connector, 850nm, up to 0.5km

The perfect converter solution for various fiber media

• Distance up to 0.5km
• Sends data in high quality and additionally provides excellent reliability
• A quick delivery is guaranteed in the gigabit range

Technical Details

• Transforms wire based network media to fiber optic
• High quality and excellent reliability
• 10/100/1000Base-TX to 1000Base-SX
• Connectors: 1x RJ45, 1x SC duplex
• Distance up to 0.5km
• Wavelength: 850nm
• Multimode dual fiber
• Automatic cable detection - auto MDI / MDI-X function
• Auto-negotiation of full- and half-duplex
• Diagnostic and monitoring LEDs for the status of power, link and act of the ports
• Suitable for 50/125µm and 62.5/125µm Fiber Cables
• Transmission Power: Minimum -17 dBm, Maximum -12 dBm
• Sensitivity Receiving Power: Minimum -20 dBm
• Supported Standards: IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3z Gigabit Ethernet
• 2MB Data Buffer
• Operating Temperature: 0 to 60°C
• Dimensions (L x W x H): 95mm x 70mm x 26mm
• Weight: 200g
• Standalone Converter with external power supply
• Input Supply Voltage: 5V DC
• Industrial usage: no
• PoE injector: no
• USB-C Products: no
• Broadcasting Mode: Unidirectional
• Connector 1: RJ45
• Connector 2: SC
• Distance (km): 0.5
• Mode: Multimode
• Ethernet speed: Gigabit

Package content

• Media Converter
• Quick installation guide
• Power adapter
