Digitus PCIe Serial Interface Card 2x DS-30000-1
Κωδικός plus26: 6205-01
Κωδικός Εργοστασίου (MPN): DS-30000-1
This PCI Express based serial Add-On card allows you to turn a PCI Express slot into two RS232 (DB9) serial ports. Based on a native single chip design reduces the load applied to the CPU by as much as 48% over conventional serial cards.
Serial I/O,2-port, PCIexpress Add-On card 2 X DB9 M , Slot Bracket + LP Brackets ASIX99100 chipset
Perfect for connecting serial modems, PDAs, digital cameras, printers, ISDN terminal adapters and many more
- Data transfer rate up to 230, 400 bps
- Compliant with PCI Express base specification 1.1
- 2 x DSUB 9, serial ports, male, UART 16C950
This PCI Express based serial Add-On card allows you to turn a PCI Express slot into two RS232 (DB9) serial ports. Based on a native single chip design reduces the load applied to the CPU by as much as 48% over conventional serial cards.
Technical Details
- 2 x DSUB 9, serial ports, male, UART 16C950
- Chipset: MCS9901
- Data transfer rate up to 1,5 Mbps
- Compliant with PCI Express base specification 1.1
- Compliant with PCI power management 1.2
- Operating temperature: 0 °C - 70 °C
- Operating humidity: 25% - 65% RH (non-condensing)
- Supports Windows 10, 8.1, 8, 7, Vista, XP, macOS X and Linux
Package content
- 2-Port Serial Interface Card, PCIe
- Low profile bracket
- Manual
- Driver CD
