HARDWARE FEATURES
Interface 1× Gigabit Ethernet Port (supports 802.3at PoE or 48V Passive PoE)
Button Reset
Power Supply • 802.3at PoE
• 48V Passive PoE
Max. Power Consumption • EU: 12.5W (802.3at PoE or Passive PoE)
• US: 14.7W (802.3at PoE or Passive PoE)
Dimensions ( W x D x H ) 8.2 × 2.3 × 9.1 in (207.5 × 58 × 230 mm)
Antenna Built-in Directional Antennas:
• 2.4 GHz: 2× 8 dBi
• 5 GHz: 2× 10 dBi
Beamwidth: 120° Horizontal; 30° Vertical
Bluetooth Yes
Weatherproof Enclosure IP68
Mounting Optional bracket accessory APM-100:
Supports vertical ±45° , horizontal ±45° adjustment
Note: Optional bracket accessories need to be purchased separately

WIRELESS FEATURES
Coverage • 2.4 GHz: 200+ m*
• 5 GHz: 500+ m*
Concurrent Clients 250+**
Wireless Standards IEEE 802.11 a/b/g/n/ac/ax
Frequency 2.4 GHz, 5 GHz
Signal Rate 574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz)†
Wireless Functions • 1024-QAM
• DL/UL OFDMA
• Multiple SSIDs (Up to 16 SSIDs, 8 on each band)
• Enable/Disable Wireless Radio
• Enable/Disable SSID Broadcast
• Guest Network
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS (WMM)
• 2 × 2 (2.4 GHz & 5 GHz) DL/UL MU-MIMO
• Omada Mesh§
• Seamless Roaming(802.11k/v/r)§
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• RADIUS Accounting
• MAC Authentication
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics
• Static IP/Dynamic IP
Wireless Security • Captive Portal Authentication§
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power • CE: < 20 dBm (2.4GHz, EIRP); < 23dBm (5 GHz, band1 & band 2, EIRP);< 30 dBm (5 GHz,band 3, EIRP);
• FCC: < 30 dBm (2.4 GHz); < 30 dBm (5 GHz)

Management Features
Omada App Yes
Restore & Backup Yes
NTP Yes
Centralized Management • Omada Hardware Controller
• Omada Software Controller
• Omada Cloud-based Controller
• Omada APP
Cloud Access Yes. Require the use of an Omada controller.
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1, v2c, v3
System Logging Local/Remote Syslog Yes
SSH Yes
Web-based Management Yes
Multi-site Management Yes
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller

OTHERS
Certification CE, FCC, RoHS
Package Content • Access Point EAP650 D120-Outdoor
• Mounting Kits
• Installation Guide
System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Environment • Operating Temperature: -30–70 ℃ (-22–158 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
