Gigabit Ethernet Media Converter, Singlemode SC connector, 1310nm, up to 20km

The perfect converter solution for various fiber media

• Distance up to 20km
• Sends data in high quality and additionally provides excellent reliability
• A quick delivery is guaranteed in the gigabit range

The media converters from DIGITUS® are the ideal solution for the migration of copper and fiber network signals. From now on, you are able to access the fiber technology and transfer network signals over several kilometers without renewing your whole network infrastructure. The huge variety of products fulfil your individual needs. The intiutive operation guarantees a quick and easy installation.

Technical Details

• Transforms wire based network media to fiber optic
• High quality and excellent reliability
• 10/100/1000Base-TX to 1000Base-LX
• Connectors: 1x RJ45, 1x SC duplex
• Distance up to 20km
• Wavelength: 1310nm
• Singlemode Dual Fiber
• Automatic cable detection - auto MDI / MDI-X function
• Auto-negotiation of full- and half-duplex
• Diagnostic and monitoring LEDs for the status of power, link and act of the ports
• Suitable for 9/125µm Fiber Cables
• Transmission Power: Minimum -12 dBm, Maximum -6 dBm
• Sensitivity Receiving Power: Minimum -21 dBm
• Supported Standards: IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3z Gigabit Ethernet
• 2MB Data Buffer
• Operating Temperature: 0 to 60°C
• Dimensions (L x W x H): 95mm x 70mm x 26mm
• Weight: 200g
• Standalone Converter with external power supply
• Input Supply Voltage: 5V DC
• Industrial usage: no
• PoE injector: no
• USB-C Products: no
• Broadcasting Mode: Unidirectional
• Connector 1: RJ45
• Connector 2: SC
• Distance (km): 20
• Mode: Singlemode
• Ethernet speed: Gigabit

Package content

• Media Converter
• Quick installation guide
• Power adapter
