HARDWARE FEATURES
Interface 1 x 10M/100M/1000M/2.5Gbps Ethernet Port (RJ45)
Button Reset
Power Supply 802.3at PoE
Max. Power Consumption 18.4W (for PoE+)
Dimensions ( W x D x H ) 8.19 x 6.3 x 2.17 in (208 × 160 × 55 mm)
Antenna • 2.4 GHz:
2 × 4.5 dBi, external omnidirectional antennas
2 × 8.3 dBi, internal directional antennas (antenna beamwidth 90°)

• 5 GHz:
2 × 5.3 dBi, external omnidirectional antennas
2 × 13.2 dBi, internal directional antennas (antenna beamwidth 45°)

Note: The gains above are the single-antenna peak gains.
Bluetooth BLE 5.2
Weatherproof Enclosure IP66
Mounting Pole/Wall Mounting (Kits included)

WIRELESS FEATURES
Wireless Standards IEEE 802.11a/g/b/n/ac/ax/be
Frequency 2.4 GHz, 5 GHz
Signal Rate 688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz)
Wireless Functions • 4k-QAM
• OFDMA
• Multiple SSIDs: 16 (8 for each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS (WMM)
• MLO
• Omada Mesh§
• Seamless Roaming(802.11k/v/r)§
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client
• Static IP/Dynamic lP
Wireless Security • Captive Portal Authentication§
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE
Transmission Power • CE: (EIRP)
2.4 GHz: 20 dBm
5 GHz: 23 dBm in U-NII-1, 23 dBm in U-NII-2A, 30 dBm in U-NII-2C
• FCC: (Conducted Power)
2.4 GHz: 25 dBm
5 GHz: 26 dBm in U-NII-1, 24 dBm in U-NII-2A, 24 dBm in U-NII-2C, 26 dBm in U-NII-3

Management Features
Omada App Yes
Centralized Management • Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
Cloud Access Yes. Require the use of an Omada controller.
Email Alerts Yes
Management MAC Access Control Yes
SNMP v1, v2c, v3
System Logging Local/Remote Syslog Yes
SSH Yes
Web-based Management Yes
L3 Management Yes
Multi-site Management Yes
Management VLAN Yes
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller

OTHERS
Certification CE, FCC, RoHS, IC, NCC, VCCI, JRF, BSMI
Package Content • Access Point EAP725-Outdoor
• Waterproof Kit
• Mounting Kit
• Installation Guide
System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Environment • Operating Temperature: -30 to 70 ℃ (-22 to 158 ℉)
• Storage Temperature: -40 to 70 ℃ (-40 to 158 ℉)
• Operating Humidity: 10 to 90% RH non-condensing
• Storage Humidity: 5 to 90% RH non-condensing
Weight Main Unit: 1.33 kg
