The DIGITUS® mini GBIC (SFP) transceiver modules offer highest quality and reliability. Wether from switch to switch, converter to switch, converter to converter or any else application: The wide product range of DIGITUS® modules makes possible a flexible usage of the fiber technology. The conformity to the MSA (Multi Source Agreement) standard ensures a compatibility to third party manufacturers.

Technical details

• Mini GBIC SFP (Small Form Factor Pluggable) module
• Supports DDM (Digital Diagnostic Monitoring)
• High quality and excellent reliability
• 10 Gbps Maximum Data Rate
• Compliant to IEEE802.3ae 10 Gigabit Standard
• Class 1 laser product compliant with EN 60825-1
• Easy plug-and-play installation
• MSA (Multi Source Agreement) compliant
• Hot pluggable
• Connector: 1x LC Duplex
• Wavelength: 1310nm
• Transmission Power: Minimum -8 dBm, Maximum -0,5 dBm
• Sensitivity Receiving Power: Minimum -12.5 dBm
• For a distance of up to 10,0km
• Safe fast-locking mechanism
• Operating temperature: 0 °C ~ 70 °C
• HP compatible
• HP-Aruba compatible

Attributes

• Mode: Singlemode
• Connector: LC
• Distance (km): 10
• Wavelength: 1310 nm
• DDM Support: yes
• Broadcasting Mode: Unidirectional
• Manufacturer compatibility: HP
• Ethernet speed: 10 Gigabit

Package content

• SFP module
