Description

This active HDMI AOC Hybrid Fiber Optic Cable is ideally suited for transferring uncompressed video and audio data with high bandwidth over longer distances. The hybrid construction, which uses copper and fiber optic cable, prevents electromagnetic interference. This ensures a loss-free transfer along the entire length of the cable with UHD resolution of up to 8K/60Hz and bandwidths of up to 48 Gbps. The use of fiber optic cable keeps the diameter of this active cable very low and gives it a very tight bending radius and low weight. It is ideal for use in homes, meeting rooms, and conference rooms as well as within buildings — and these are just a few of the possible uses. The simple Plug and Play installation is user-friendly; just plug it in and immediately enjoy optimal image quality. It supports numerous standards such as HDMI 2.1, HDCP 2.2 and HDR. Some of the many audio features supported are ARC, DTS-HD Master Audio and Dolby TrueHD. Cutting edge chip technology makes it possible to transfer the full HDMI signal spectrum while also supporting uncompressed CED and EDID with very low latency.

Technical details

Resolution: 7680 x 4320p / 60 Hz (UHD-2)
Supports 8K 3D
Data transfer rate up to 48 Gbps - zero frame delay
Supports up to 60Hz at 4K & Full HD (1080p)
Supports BT.2020 with 10, 12 and 16 Bit per color component
Subsampling: YUV 4:4:4
HDCP version: 2.2
HDMI version: 2.1
Supported color depth: 48 Bit Deep Color
Supports HDR
Supports enhanced Audio Return Channel (eARC)
Supports Consumer Electronic Control (CEC)
Supports Lip Sync (audio/video synchronization)
With Ethernet channel (HEC)
Multi Stream audio/video support
Supports EDID 2.0 (device recognition)
Supports 21:9 Cinemascope
32 channel audio support
Dolby TrueHD capable
Supports 8-channel LPCM, 192 kHz, 24-bit audio capability
Supports DTS-HD Master Audio bitstream
Supports Super Audio CD (DSD)
Supports DVD audio
Supports Blu-ray Disc and HD DVD audio and video
Latency: Zero frame delay
Bending radius: 20 mm
OM version: OM3
Operating temperature: -10 ~80°C
Operating humidity: 0% - 85% RH
Power consumption: 400 mW max.
Supports DVI Version 1.0 (in conjunction with adapters)

Attributes

Color cable: black
Connector 1: HDMI type A, plug
Connector 2: HDMI type A, plug
Connector surface: gold-plated
HDMI Standard: Ultra High Speed HDMI
HDTV Resolution max.: 7680 × 4320 Pixel, 60Hz
HDTV Standard: Ultra HD 8K
Hoods: Metallic housing
Length: 10 m
AOC - Active Optical Cable: yes
Shielding: single shielding
