HARDWARE FEATURES

• Standards and Protocols IEEE 802.3i / 802.3u / 802.3ab/ 802.3x /802.1p
• Interface 8 10/100/1000Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX
• Fan Quantity Fanless
• External Power Supply External Power Adapter (Output: 9VDC / 0.6A)
• Buffer Size 1.5Mb
• LED Indicator System Power
• Link/Act indicators per port built into each RJ-45 port
• Dimensions ( W x D x H ) 6.2 x 4.0 x 1.0 in. (158 x 101 x 25 mm)
• Max Power Consumption 3.31W(220V/50Hz)
• Max Heat Dissipation 11.29BTU/h

PERFORMANCE

• Packet Forwarding Rate 11.9Mpps
• MAC Address Table 4K
• Packet Buffer Memory 1.5Mb
• Jumbo Frame 16KB

SOFTWARE FEATURES

• Advanced Features Green Technology, saving power up to 82%
• 802.3X Flow Control
• 802.1p/DSCP QoS
• IGMP Snooping
• Transfer Method Store and Forward

OTHERS

• Certification CE, FCC ,RoHS
• Package Contents 8-Port 10/100/1000Mbps Desktop Switch
• Power Adapter
• Installation Guide
• Environment Operating Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -40°C~70°C (-40°F~158°F)
• Operating Humidity: 10% ~ 90%, non-condensing
• Storage Humidity: 5%~90% non-condensing
