Category
6

Type of connector connection 1
RJ45 8(8)

Type of connector connection 2
RJ45 8(8)

Connector type
RJ45 Standard

Contacts
Gold plated

Pin assignment
1:1

Allocation
acc. TIA/EIA 568B

Type
Shielded

Length imprint
yes

Anti-kink sleeve
moulded

Colour anti-kink sleeve
black

Locking lever
yes

Mating cycles
≥750

Bending radius
>31 mm

Conductive shield
Selected shield contact

Cable type
S/FTP

Cable construction
4x2

AWG-size
27/7

Conductor Material
Copper

Silicone-free
yes

Jacket material
LSZH

Colour outer sheath
black

Printing
Cat.6 S/FTP 4x2xAWG27/7 PIMF ISO/IEC 11801 & EN50173-1 TIA/EIA 568B.2-1 Halogen Free ***Gigabit***

Outer diameter of the cable
6.2 mm

Flame-retardant
acc. IEC60332-1

Halogen-free
yes

Low smoke
yes

Temperature range
0 – 60 °C

NVP value
- %

Conductor resistance DC
185 Ω/km

Loop resistance
370 Ω/km

Resistance unbalance
5 %

Insulation resistance
10 MΩ

Contact resistance
30 mΩ

POE class
PoE acc. to IEEE802.3af;PoE+ acc. to IEEE802.3at;4PPoE acc. to IEEE802.3bt

Bandwidth
250MHz

Connector
IEC 60603-7-5
