PRODUCT DETAILS

Fiber optic patch cables are defined components of an internationally standardized structured cabling of ISO / IEC11801.
Many different connectors have historically grown in structured cabling, whereby the following are still relevant: LC, SC, E2000®, MPO / MTP

A fiber optic patch cable represents the shortest connection between a passive cabling port and an active network port or a point-to-point connection. Point connection of two active network ports.
Quality classes allow a qualitative differentiation of the fiber optic patch cables depending on the network service.

Identical designations for patch cables: patch cords, adapter cables, connection cables, hybrid cables, jumpers, connecting cords Features of EFB fiber optic patch cables
Strain relief reinforced with aramid yarn

Halogen-free and flame-retardant jacket according to IEC-60754-2, IEC-60332-1 and IEC-61034
EFB fiber optic connectors meet the minimum quality class Grade B / 2 according to IEC-61753-1 for singlemode and Grade A / 1 for Multimode according to IEC 61753-122-2 (UPC cut)
100% tested and with individual measurement protocol

Fiber type Singlemode 9/125

category OS2

Bend-optimized fiber No

Number of fibers 2

Anti-kink sleeve attached

Connector type connection 1 LC duplex

Connector connection 1 color blue

Connector type connection 2 SC duplex

Connector connection 2 color blue

Maximum pulling force 160 N

Minimum bending radius (static) 10xOD

Minimum bending radius (dynamic) 20xOD

Cable type IV (ZN) H

Cable structure Duplex

Cable Ø 2.0 mm

Coat color yellow

Sheath material LSZH

Flame retardant according to EN 50265-2-1

Halogen free according to IEC60754-1

Low smoke according to IEC61034-1

Working temperature -20 - 70 ° C

Storage temperature -20 - 85 ° C

Quality class singlemode B / 2 according to IEC 61753-1

Cable conforms to standard IEC 60793-2
