WIRELESS
Standards Wi-Fi 4
IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds N300
2.4 GHz: 300 Mbps (802.11n)
WiFi Range 2 Bedroom Houses
2× Fixed Antennas
WiFi Capacity Legacy
Working Modes Router Mode
Access Point Mode
Range Extender Mode
Client Mode
Hotspot Mode (WISP Mode)

HARDWARE
Processor Single-Core CPU
Ethernet Ports 1× 10/100 Mbps WAN/LAN Port
Buttons Κουμπί επαναφοράς
Power 5 V ⎓ 1 A

SECURITY
WiFi Encryption WEP
WPA
WPA2
WPA/WPA2-Enterprise (802.1x)
Network Security SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
Guest Network 1× 2.4 GHz Guest Network

SOFTWARE
Protocols IPv4
IPv6
Parental Controls URL Filtering
Time Controls
WAN Types Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Quality of Service QoS by Device
NAT Forwarding Virtual Server
Port Forwarding
Port Triggering
DMZ
UPnP
IPTV IGMP Proxy
DHCP Address Reservation
DHCP Client List
Server
DDNS NO-IP
Comex
DynDNS
Management Tether App
Webpage
Check Web Emulator>

PHYSICAL
Dimensions (W×D×H) 2.2 × 2.2 × 0.7 in
(57 × 57 ×18 mm)
Package Contents Δρομολογητής Wi-Fi TL-WR802N
Τροφοδοτικό
Καλώδιο USB
Καλώδιο RJ45 Ethernet
Οδηγός γρήγορης εγκατάστασης
CD πόρων

OTHER
System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)
Certifications FCC, CE, RoHS
Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

TEST DATA
WiFi Transmission Power CE:
<20dBm(2.4GHz)
FCC:
<30dBm
WiFi Reception Sensitivity 270M: -70dBm@10% PER
130M: -75dBm@10% PER
108M: -88dBm@10% PER
54M: -78dBm@10% PER
11M: -100dBm@8% PER
6M: -92dBm@10% PER
1M: -100dBm@8% PER
