• Easy-grip knobs for quick tilt and lock
• Swiveling arm(s) offer(s) maximum viewing flexibility
• Open architecutre provides increased ventilation and easier access to wires

Τεχνικά Χαρακτηριστικά:

• Function: Full motion
• By Mounting Pattern: Standard VESA
• Material: Steel, Plastic
• Pipe Size: 40x20mm (1.6"x0.79")
• Surface Finish: Powder Coating
• Available Color: Black
• Product Size With Open Position: 205x230x255mm (8.1"x9.1"x10")
• Fit Screen Size: 23"-42"
• Installation: Solid wall
• Rated Load: 30kg (66lbs)
• Strength tested: 2 times approved
• Max.Hole Pattern: 200x200mm
• VESA: 100x100, 200x100, 200x200
• Tilt: +3°~-10°
• Swivel: +90°~-90°
• Profile: 56-205mm (2.2"-8.1")

Περιεχόμενα συσκευασίας:

• βάση
• βίδες
• εργαλεία
• user manual

• By Function: Full motion
• By Mounting Pattern: Standard VESA
• Material: Steel, Plastic
• Pipe Size: 40x20mm
• Surface Finish: Powder Coating
• Available Color: Black
• Product Size With Open Position: 205x230x255mm
• Suggested Screen Size: 23"-42"
• Installation: Solid wall
• Rated Load: 30kgs/66lbs
• Strength tested: 2 times approved
• Max.Hole Pattern: 200x200mm
• VESA: 100x100;200x100;200x200
• Tilt: ＋3°～-10°
• Swivel: +90°~-90°
• Profile: 56-205mm
• Bubble Level: No
• Anti-theft: No
• Cable Management: No
• Wall separated: No
• Panel separated: Yes
• AV Component Mount: No
• Freely Tilting: No
• Freely Height Adjustable: No
• Motorized: No
• Curved TV Available: NO
• User Manual : Yes
• Power Plug: NO
• Magnetic: NO
